| Features |
GS510TPP |
| 10M/100M/1G RJ-45 copper ports |
8 |
| PoE / PoE+ ports |
8 PoE+ (190W PoE budget) |
| 100M/1G SFP (fiber) ports |
2 (dedicated) |
| USB port (for config file upload/backup & firmware updates) |
No |
| PERFORMANCE SPECIFICATION |
|
| CPU |
400 MHz Cortex-A9 Single Core, 512MB RAM 16MB SPI + 256MB NAND FLASH |
| Packet buffer memory(Dynamically shared across only used ports) |
1.5 MB |
| Forwarding modes |
Store-and-forward |
| Bandwidth |
20 Gbps |
| Priority queues |
8 |
| Priority queuing |
Weighted Round Robin (WRR) and Strict Priority |
| MAC Address database size(48-bit MAC addresses) |
16K |
| Multicast groups |
512 |
| Number of IPv4 static routes |
32 |
| Number of IPv6 static routes |
32 |
| Number of VLANs |
256 |
| Number of ARP cache entries |
479 ARP / 223 NDP |
| Number of DHCP snooping bindings |
8k |
| Access Control Lists (ACLs) |
100 shared for MAC, IP and IPv6 ACLs |
| Packet forwarding rate(64 byte packet size) (Mpps) |
14.88 |
| Jumbo frame support |
Up to 9K packet size |
| Acoustic noise level @ 25°C (dBA)(ANSI-S10.12) |
32 dBA |
| Mean Time Between Failures (MTBF) @ 25°C |
1,509,979 hours |
| 100M Copper Latency(64-byte; 1518-byte; 9216-byte frames) |
8.725µs ; 7.933µs ; 8.119µs |
| 1G Copper Latency(64-byte; 1518-byte; 9216-byte frames) |
3.313µs ; 3.322µs ; 3.293µs |
| 1G Fiber Latency(64-byte; 1518-byte; 9216-byte frames) |
2.402µs ; 2.405µs ; 2.372µs |
| L2 SERVICES - VLANS |
|
| IEEE 802.1Q VLAN tagging |
Yes |
| IP-based VLANs |
Yes |
| MAC-based VLANs |
Yes |
| Auto-VoIP VLAN / Auto-Voice VLAN |
Yes, based on OUI bytes (default database and user-based OUIs) in the phone source MAC address |
| Auto-VoIP |
Yes, based on protocols (SIP, H.323 and SCCP). Prioritzes traffic to a higher queue |
| Voice VLAN |
Yes, based on either VLAN ID or 802.1p priority,packets are passed onto the connecting VoIP phone using LLDP-MED |
| Auto-Video VLAN |
Yes |
| Private VLAN |
Yes |
| L2 SERVICES - AVAILABILITY |
|
| Broadcast, multicast, unknown unicast storm control |
Yes |
| IEEE 802.3ad - LAGs (LACP) |
Yes |
| IEEE 802.3x (full duplex and flow control) |
Yes |
| IEEE802.1DSpanningTreeProtocol |
Yes |
| IEEE802.1wRapidSpanningTreeProtocol |
Yes |
| IEEE802.1sMultipleSpanningTreeProtocol |
Yes |
| Layer2DHCPRelay |
Yes |
| L2 SERVICES - MULTICAST FILTERING |
|
| IGMP snooping (v1, v2 and v3) |
Yes |
| MLD snooping support (v1 and v2) |
Yes |
| IGMP snooping queries |
Yes |
| Multicast VLAN Registration (MVR) |
Yes |
| Block unknown multicast |
Yes |
| L3 SERVICES - DHCP |
|
| DHCP client |
Yes |
| DHCP snooping |
Yes |
| L3 SERVICES - ROUTING |
|
| IPv4 static routing |
32 |
| IPv6 static routing |
32 |
| VLAN routing |
Yes |
| Host ARP table (number of entries) |
479 ARP / 223 NDP |
| ICMP Router Discovery Protocol (IRDP) |
Yes |
| Number of IP VLAN interfaces (routed VLANs) |
15 |
| LINK AGGREGATION |
|
| IEEE 802.3ad - LAGs (LACP) |
Yes |
| Manual Static LAG |
Yes |
# of Static or LACP LAGs
# of members in each LAG |
5 LAGs with max 8 members in each LAG |
| NETWORK MONITORING AND DISCOVERY SERVICES |
|
| 802.1ab LLDP |
Yes |
| SNMP |
v1, v2c, v3 |
| RMON group 1,2,3,9 |
Yes |
| NETWORK SECURITY |
|
| IEEE 802.1x |
Yes |
| Guest VLAN |
Yes |
| RADIUS-based VLAN assignment via .1x |
Yes |
| MAC-based .1x |
Yes |
| RADIUS accounting |
Yes |
| Access Control Lists (ACLs) |
L2 / L3 / L4 ingress |
| IP-based ACLs (IPv4 and IPv6) |
Yes |
| MAC-based ACLs |
Yes |
| TCP/UPD-based ACLs |
Yes |
| MAC lockdown |
Yes |
| MAC lockdown by the number of MACs |
Yes |
| Control MAC # Dynamic learned entries |
4096 |
| Control MAC # static entries |
96 |
| IEEE 802.1x RADIUS port access authentication |
Yes |
| Port-based security by locked MAC addresses |
Yes |
| Dynamic ARP inspection |
Yes |
| Broadcast, multicast, unknown unicast storm control |
Yes |
| DoS attacks prevention |
Yes |
| QUALITY OF SERVICE (QOS) |
|
| Port-based rate limiting |
Yes egress |
| Port-based QoS |
Yes |
| Support for IPv6 fields |
Yes |
| DiffServ QoS |
Yes ingress |
| IEEE 802.1p COS |
Yes |
| Destination MAC and IP |
Yes |
| IPv4 and v6 DSCP |
Yes |
| IPv4 and IPv6 ToS |
Yes |
| TCP/UDP-based |
Yes |
| Weighted Round Robin (WRR) |
Yes |
| Strict priority queue technology |
Yes |
| Auto-VoIP VLAN / Auto-Voice VLAN |
Yes, based on OUI bytes (default database and user-based OUIs) in the phone source MAC address |
| Auto-VoIP |
Yes, based on protocols (SIP, H.323 and SCCP). Prioritzes traffic to a higher queue |
| Voice VLAN |
Yes, based on either VLAN ID or 802.1p priority, packets are passed onto the connecting VoIP phone using LLDP-MED |
| Auto-Video VLAN |
Yes |
| IEEE NETWORK PROTOCOLS |
• IEEE 802.3 Ethernet
• IEEE 802.3u 100BASE-T
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3af PoE
• IEEE 802.3at PoE+
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3ad Trunking (LACP)
• IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
• IEEE 802.3x Full-Duplex Flow Control
• IEEE 802.1Q VLAN Tagging
• IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED)
• IEEE 802.1p Class of Service
• IEEE 802.1D Spanning Tree (STP)
• IEEE 802.1s Multiple Spanning Tree (MSTP)
• IEEE 802.1w Rapid Spanning Tree (RSTP)
• IEEE 802.1x RADIUS Network Access Control |
| MANAGEMENT |
|
| Password management |
Yes |
| Configurable management VLAN |
Yes |
| Admin access control via RADIUS and TACACS+ |
Yes |
| IPv6 management |
Yes |
| SNTP client over UDP port 123 |
Yes |
| SNMP v1/v2c |
Yes |
| SNMP v3 with multiple IP addresses |
Yes |
| RMON group 1,2,3,9 |
Yes |
| Port mirroring |
Yes |
| Many-to-one port mirroring |
4 |
| Web browser-based graphical user interface (GUI) |
Yes (English, German and Japanese supported) |
| Smart Control Center (SCC) for multi-switch management |
Yes |
| Dual software (firmware) image |
Yes |
| Dual configuration file |
Yes |
| Cable test utility |
Yes |
| SSL/HTTPS Web-based access (version) |
Yes (v3) |
| TLS Web-based access (version) |
Yes (v1.0) |
| File transfers (uploads, downloads) |
TFTP / HTTP |
| HTTP upload/download (firmware) |
Yes |
| Syslog (RFC 3164) |
Yes |
| USB port for firmware and config upload / download |
No |
| LEDS |
|
| Per port |
Speed, Link, Activity |
| Per device |
Power and Fan |
| PHYSICAL SPECIFICATIONS |
|
| Dimensions (W x D x H) |
328 x 169 x 43 mm (12.9 x 6.7 x 1.7 in) |
| Weight |
1.83 kg (4.03 lb) |
| POWER CONSUMPTION |
|
| Max power (worst case, all ports used, full PoE, line-rate traffic) (Watts) |
225 W |
| Max power without PoE (worst case, all ports used, line-rate traffic) (Watts) |
12.5 W |
| Heat Dissipation (worst case, all ports used, full PoE, line-rate traffic) (BTU/hr) |
768.15 BTU/hr |
| Energy Efficient Ethernet (EEE) IEEE 802.3az |
Yes (deactivated by default) |
| Fan |
1 |
| ENVIRONMENTAL SPECIFICATIONS |
|
| Operating |
|
| Operating temperature |
0° to 50°C (32° to 122°F) |
| Humidity (relative) |
90% maximum relative humidity (RH), non-condensing |
| Altitude |
10,000ft (3,000m) maximum |
| Storage |
|
| Storage temperature |
–20° to 70°C (– 4° to 158°F) |
| Humidity (relative) |
95% maximum relative humidity, non-condensing |
| Altitude |
10,000ft (3,000m) maximum |
| ELECTROMAGNETIC EMISSIONS AND IMMUNITY |
|
| Certifications |
CE: EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-3-2:2014,
Class A, EN 61000-3-3:2013, EN 55024:2010
VCCI : VCCI-CISPR 32:2016, Class A
RCM: AS/NZS CISPR 32:2013 Class A
CCC: GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A)
FCC: 47 CFR FCC Part 15, Class A, ANSI C63.4:2014
ISED: ICES-003:2016 Issue 6, Class A, ANSI C63.4:2014
BSMI: CNS 13438 Class A |
| SAFETY |
|
| Certifications |
CB report / certificate IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013
UL listed (UL 1950)/cUL IEC 950/EN 60950
CE LVD: EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
RCM (AS/NZS) 60950.1:2015
CCC (China Compulsory Certificate): GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A)
BSMI: CNS 14336-1 |
| 保固 |
五年 |
